手柄JTC3200-NY是为工程机械设备开发的通用指控型单轴自复位手柄产品。该手柄满足工程机械高振动使用要求，寿命大于500万次，面板以上防护等级为IP65，适用于汽车起重机、高空作业车、消防车等工程机械恶劣的工况环境。

JTC3200-NY is a general-purpose accusatory single-axis self-resetting handle developed for construction machinery and equipment. The handle meets the requirements of high vibration use of construction machinery, life expectancy of more than 5 million times, the panel above the protection level of IP65, suitable for automobile cranes, aerial work trucks, fire trucks and other construction machinery in harsh working conditions.

超过500万次机械操作寿命，霍尔无接触原理，电气寿命超过1亿次；

手指操控位置为橡胶材质，舒适的握持手感，长期操作无疲劳感；

整体防护等级为IP65，电气部分防护等级IP67；

五种颜色可选，满足客户不同功能定义要求；

极低功耗，工作电流小于13.5mA（@5VDC）;

10%~90%Vs输出，防短路无输出设计；

每一个轴均冗余（一路正比例，一路反比例）可选，方便客户进行更高安全等级系统设计。

More than 5 million times mechanical operation life, Hall contactless principle, electrical life of more than 100 million times;

Finger control position is made of rubber, comfortable grip feeling, long-term operation without fatigue;

Overall protection class IP65, electrical part protection class IP67;

Five colors are available to meet the different functional definition requirements of customers;

Extremely low power consumption, the working current is less than 13.5mA (@5VDC);

10%~90%Vs output, anti-short-circuit no output design;

Redundancy for each axis (one positive and one negative) is optional, which is convenient for customers to carry out higher safety level system design.
