手柄JTC3300-NY是我司为工程机械设备开发的通用单轴自复位手柄产品，该手柄满足工程机械高振动使用要求，寿命大于600万次，面板以上防护等级为IP65，内部电气防护等级IP67，适用于高空作业车、消防车等工程机械恶劣的工况环境。

JTC3300-NY is a general-purpose single-axis self-resetting handle developed by our company for construction machinery and equipment. The handle meets the requirements of high vibration use in construction machinery, with a life span of more than 6 million times, a protection level of IP65 above the panel and an internal electrical protection level of IP67, which is suitable for aerial work trucks, fire trucks, and other construction machinery in the harsh working conditions of the environment.

超过600万次机械操作寿命；

手柄顶部自带翘板开关，提供更多操控设计；

每一个轴均冗余（一路正比例，一路反比例）可选，方便客户进行更高安全等级系统设计；

面板以上防护等级为IP65；

10%~90%Vs输出，防短路无输出设计。

Over 6 million mechanical operations life;

The handle comes with its own rocker switch at the top to provide more control design;

Redundancy in each axis (one positive and one negative) is available for higher safety level system design;

Protection class IP65 above the panel;

10%~90% Vs output, anti-short circuit no output design.
