手柄JTC3300-NY是我司为工程机械设备开发的通用单轴摩擦定位产品，该手柄操作力满足工程机械高振动使用要求，寿命大于100万次（100万次后操作力衰减不超过20%），面板以上防护等级为IP65，内部电气防护等级IP67，适用于铣刨机、装载机、压路机、摊铺机等工程机械恶劣的工况环境。

JTC3300-NY is a general-purpose single-axis friction positioning product developed by our company for construction machinery and equipment. The operating force of this handle meets the requirements of high vibration use in construction machinery, with a life span of more than 1 million times (the operating force will not be attenuated by more than 20% after 1 million times), with a protection level of IP65 above the faceplate and an internal electrical protection level of IP67, and it is suitable for use in harsh working environments of milling planes, loaders, rollers, pavers, and other construction machinery. It is suitable for milling planers, loaders, rollers, pavers and other construction machinery in harsh working conditions.

100万次后操作力衰减不超过20%；

提拉锁止，避免工程机械恶劣环境下得可能误操作；

10%~90%Vs输出，防短路无输出设计；

每一个轴均冗余（一路正比例，一路反比例）可选，方便客户进行更高安全等级系统设计；

面板以上防护等级为IP65；

极低功耗，工作电流小于13.5mA（@5VDC）。

The operating force will not be reduced by more than 20% after 1,000,000 times;

Lifting and pulling locking to avoid possible misoperation under the harsh environment of construction machinery;

10%~90%Vs output, anti-short-circuit no output design;

Each axis is redundant (all the way forward proportion, all the way reverse proportion) optional, convenient for customers to carry out a higher level of security system design;

The protection level above the panel is IP65;

Extremely low power consumption, the working current is less than 13.5mA (@5VDC).
