手柄JTC3201-XY是为工程机械设备开发的通用指控型双轴自复位手柄产品。该手柄满足工程机械高振动使用要求，寿命大于500万次，面板以上防护等级为IP65，适用于汽车起重机、高空作业车、消防车等工程机械恶劣的工况环境。

JTC3201-XY is a general-purpose allegation-type dual-axis self-restoring handle developed for construction machinery and equipment. The handle meets the high vibration requirements of construction machinery, life of more than 5 million times, the panel above the protection level of IP65, suitable for automobile cranes, aerial work trucks, fire trucks and other construction machinery, the harsh working conditions of the environment.Translated with DeepL.com (free version).

超过500万次机械操作寿命；

手指操控位置为橡胶材质，舒适的握持手感，长期操作无疲劳感；

极低功耗，工作电流小于13.5mA（@5VDC）每一个轴均冗余（一路正比例，一路反比例）可选，方便客户进行更高安全等级系统设计；

10%~90%Vs输出，防短路无输出设计；

整体防护等级为IP65，电气部分防护等级IP67；

28mm底部安装深度尺寸，轻松应对各种狭小安装空间。

More than 5 million times mechanical operation life

Finger control position is made of rubber, comfortable grip, long-term operation without fatigue;

Extremely low power consumption, the working current is less than 13.5mA (@5VDC) each axis are redundant (a positive proportion, a reverse proportion) optional, convenient for customers to carry out a higher level of security system design;

10%~90%Vs output, anti-short-circuit no output design;

Overall protection class IP65, electrical part protection class IP67;

28mm bottom mounting depth size, easy to deal with a variety of narrow installation space Translated with DeepL.com (free version).
