LWG200系列长度角度传感器由长度检测单元和角度检测单元组成，可以实现长度和角度的测量。该系列长度角度传感器适用于伸缩机构的长度测量和变幅机构的倾角测量，如起重机二节臂测长、伸缩式高空作业车以及支腿测长等应用。

LWG200 series length angle sensor consists of length detecting unit and angle detecting unit, which can realize length and angle measurement. This series of length and angle sensors are suitable for length measurement of telescopic mechanism and inclination measurement of luffing mechanism, such as crane two-section boom length measurement, telescopic aerial work truck and outrigger length measurement and other applications.

测量范围最长 15m，非接触式霍尔测长机构

工作温度范围区间内误差补偿

长度分辨率最高0.1mm, 倾角分辨率最高0.01°

倾角支持震动滤波抑制

支持冗余扩展，故障诊断，符合PLd架构

三段式独立密封腔体，防护等级IP67

CE认证

Measuring range up to 15m, non-contact Hall length measuring mechanism

Error compensation within the operating temperature range

Length resolution of up to 0.1mm, tilt resolution of up to 0.01°

Vibration filter suppression for tilt angle

Supports redundant expansion, troubleshooting, and PLd compliant architecture

Individually sealed three-section chamber with IP67 protection class

CE marking
