RAT880 Angle displacement sensor
RAT880角位移传感器采用霍尔芯片，通过滤波补偿、非线性校正、温度补偿等技术保证传感器在各种恶劣工况下仍然保持极高的安全性能。该产品采用耐久性设计，结构紧凑，便于安装，可靠性高。RAT880角位移传感器适用于工程机械、消防机械、农业机械、船舶、仪器仪表、工厂自动化等领域。
RAT880 Angle displacement sensor adopts Hall chip, through filter compensation, nonlinear correction, temperature compensation and other technologies to ensure that the sensor still maintains extremely high safety performance in a variety of harsh working conditions. The product adopts durability design, compact structure, easy to install and high reliability. RAT880 Anglear displacement sensor is suitable for construction machinery, fire machinery, agricultural machinery, ships, instrumentation, factory automation and other fields.
机械参数/mechanical parameter
| 描述/Description | 技术参数/technical parameters |
|---|---|
| 工作电压/working voltage | 10~36V DC |
| 工作温度/operating temperature | －40℃～＋85℃ |
| 存储温度/storage temperature | －40℃～＋85℃ |
| 测角量程/ Angle measurement range | -180°~+180°，-72.5°~+72.5° |
| 输出信号/output signal | 4~20mA |
| 分辨率/resolution ratio | 12bit |
| 非线性度/Non-linearity | ≤±0.2% |
| 综合精度/Comprehensive accuracy | ≤±0.25% |
| 两路输入误差/Two-way input error | ≤±2% |
| 输入轴直径/Input axis diameter | 电缆 |
| 轴向承受荷载/Axial bearing load | ≤70N |
| 径向承受荷载/Radial bearing load | ≤250N |
| 防护等级/protection level | IP67 |
机械参数/mechanical parameter
| 描述/Description | 技术参数/technical parameters |
|---|---|
| 工作电压/working voltage | 10~36V DC |
| 工作温度/operating temperature | －40℃～＋85℃ |
| 存储温度/storage temperature | －40℃～＋85℃ |
| 测角量程/ Angle measurement range | -180°~+180°，-72.5°~+72.5° |
| 输出信号/output signal | 4~20mA |
| 分辨率/resolution ratio | 12bit |
| 非线性度/Non-linearity | ≤±0.2% |
| 综合精度/Comprehensive accuracy | ≤±0.25% |
| 两路输入误差/Two-way input error | ≤±2% |
| 输入轴直径/Input axis diameter | 电缆 |
| 轴向承受荷载/Axial bearing load | ≤70N |
| 径向承受荷载/Radial bearing load | ≤250N |
| 防护等级/protection level | IP67 |
