DCR10M series cable reel
DCR10M系列电缆卷筒可以实现远距离信号传输，也可以进行测量长度功能。能够在恶劣环境中可靠运行，且维护工作量低；卷簧式驱动式电缆卷筒用于控制电缆的卷起和放出，主要用于起重机，堆垛装置或废水处理技术等场合；可选配带棘轮锁止机构，自由控制伸出长度，防止伸出电缆被卷回。
The cable reel can be used for long-distance signal transmission and length measurement.Reliable operation in harsh environment, and low maintenance workload;Coiled-spring driven cable reel is used to control the rolling and discharging of cables, mainly used in cranes, stacking devices or wastewater treatment technology and other occasions;Optional with ratchet locking mechanism, free control of extended length, prevent the extended cable from being rolled back.
机械参数/mechanical parameter
| 描述/Description | 技术参数/technical parameters |
|---|---|
| 最大伸缩范围/Maximum stretch range | 10m |
| 工作温度/operating temperature | -40~+85℃ |
| 线类型/Type of line | 1×16mm2 |
| 壳体材质/shell material | 结构钢/Structural Steel |
| 振动/vibrational frequency | 30g ,10-2000Hz |
| 冲击/Impact resistance class | 500g ,1ms |
| 防护等级/protection level | IP54 |
电气参数/electric parameter
| 描述/Description | 技术参数/technical parameters |
|---|---|
| 安全载流值/Safe current carrying value | 100A |
| 电阻值/resistance value | 1.24mΩ |
| EMC抗干扰/EMC anti-interference | DIN EN 61000-6-2 |
| 动态精度/Dynamic Accuracy | ±0.3° |
| EMC发射干扰/EMC emission interference | DIN EN 61000-6-4 |
采用高压接地专用软铜电缆
High voltage grounding special soft copper cable
优化壳产品结构具有更强的抗振动冲击和抗干扰性能
The optimized shell product structure has stronger anti-vibration impact and anti-interference performance
具有棘轮锁止机构，可以方便控制电缆伸出长度
With ratchet lock structure, can easily control the length of cable extension
机械参数/mechanical parameter
| 描述/Description | 技术参数/technical parameters |
|---|---|
| 最大伸缩范围/Maximum stretch range | 10m |
| 工作温度/operating temperature | -40~+85℃ |
| 线类型/Type of line | 1×16mm2 |
| 壳体材质/shell material | 结构钢/Structural Steel |
| 振动/vibrational frequency | 30g ,10-2000Hz |
| 冲击/Impact resistance class | 500g ,1ms |
| 防护等级/protection level | IP54 |
电气参数/electric parameter
| 描述/Description | 技术参数/technical parameters |
|---|---|
| 安全载流值/Safe current carrying value | 100A |
| 电阻值/resistance value | 1.24mΩ |
| EMC抗干扰/EMC anti-interference | DIN EN 61000-6-2 |
| 动态精度/Dynamic Accuracy | ±0.3° |
| EMC发射干扰/EMC emission interference | DIN EN 61000-6-4 |
